This 100L jacketed cooking kettle is available with optional agitation for batch cooking and mixing. Wenzhou Ace Machinery offers 50L to 1000L capacities, SUS304 or SUS316L stainless steel, and model-dependent electric, steam, gas or thermal-oil heating. Fixed and tilting configurations, temperature control and other options can be discussed to match your product and production process.
100L Jacketed Cooking Kettle with Agitator | Gas, Electric or Steam
价格范围：$2,005.94 至 $2,143.55
Request a quote
A food grade stainless steel kettle offers many advantages, like easy cleaning, resistance to corrosion, and durability. Its scraper mixing system allows continuous movement of product, prevents sticking and burning, and promotes heat transfer. The handwheel provides adjustable tilting to allow easy disposal of processed product and the motor allows for stable and reliable mixing.
Main Features
- Food-grade stainless steel construction for hygiene and durability
- Jacketed heating system for fast and even heat distribution
- Built-in scraper agitator to prevent sticking and improve mixing efficiency
- Powerful motor drive system for stable operation
- Tilting kettle design for easy material discharge
- Independent control box for convenient operation
- Heavy-duty support frame for enhanced stability
- Suitable for cooking, boiling, mixing, and concentrating various food products
Main Components
- Motor: Provides driving power for the mixing system
- Scraper: Continuously mixes materials and prevents product adhesion
- Kettle Body: Stainless steel processing chamber with jacketed heating structure
- Handwheel: Controls kettle tilting for convenient discharge
- Control Box: Manages machine operation parameters
- Support Frame: Provides stable and safe equipment support
Jacket heating for cooking and processing
Slow-speed mixing and product circulation
Scrapes material from the kettle wall
Helps reduce sticking and localized overheating
Suitable for cooking, simmering, and mixing viscous products
Combines jacket heating, scraping, and high-shear mixing
Helps produce smoother emulsions and more uniform mixtures
Reduces certain types of agglomeration
Suitable for products requiring finer dispersion or emulsification
100L Jacketed Cooking Kettle
Batch size, heat source and product behavior all affect kettle selection. A sauce that thickens during cooking needs different agitation and discharge arrangements than a thin broth. At Wenzhou Ace Machinery, we configure jacketed kettles around those production details rather than assuming one setup fits every process.
Heat is applied through the jacket around the product vessel, so the heating medium does not contact the batch directly. Indirect heating supports controlled cooking for products such as gravy, jam, soup and dairy mixtures. Available heat sources include electric, steam, gas and thermal oil; compatibility depends on the selected model. An optional agitator can help keep ingredients moving during heating, with the stirring arrangement determined by product and configuration.
Features and production considerations
- 50L to 1000L capacities: Match kettle volume to batch size, usable fill level and production schedule.
- Fixed or tilting vessel: Tilting may help empty viscous fillings; manual or hydraulic operation is available where supported by the model.
- Optional controls and insulation: Temperature control, variable-speed drive, insulation and a control panel can be discussed for compatible configurations.
- SUS304 or SUS316L: Select contact material with the product and cleaning conditions in mind.
Applications
Typical food uses include sauces, dressings, gravy, fruit jam and filling, soup, stock, syrup, confectionery mixtures and dairy blends. Other potential applications include cosmetic creams, lotions and personal-care liquids; pharmaceutical liquids or excipient dispersions; and compatible water-based coatings, adhesives and emulsions. Suitability depends on formulation, materials, seals, cleaning procedure and process requirements. A standard kettle configuration is not suitable for every product.
Technical specifications
| Item | Details |
|---|---|
| Product name | Jacketed cooking kettle |
| Available capacity | 50L, 100L, 200L, 300L, 500L and 1000L |
| Material | SUS304 or SUS316L stainless steel |
| Heating | Electric, steam, gas or thermal oil; model-dependent |
| Vessel configuration | Fixed or tilting, depending on model |
| Tilting option | Manual or hydraulic where applicable |
| Agitation | Optional; configuration depends on product and model |
| Temperature control | Optional, configuration-dependent |
| Customization | Available on request |
FAQ
Can every capacity use every heat source? No. Confirm capacity and heating compatibility with us.
Is an agitator included? It is an optional feature; share viscosity and mixing needs.
Can the kettle tilt? Tilting and its operating method depend on the selected model.
How do I choose material? Provide product ingredients and cleaning conditions so material suitability can be reviewed.
What information helps with a quotation? Send batch size, product, preferred heat source, agitation, discharge and installation requirements.
Discuss your configuration
Wenzhou Ace Machinery provides factory-direct manufacturing and customization based on product characteristics, batch scale, heating needs and workflow. Contact our team with your required capacity, process product, heat source, and stirring or tilting requirements so we can discuss a suitable kettle configuration.
