This 100L industrial jacketed cooking kettle offers indirect heating and an optional agitator for controlled batch processing. Select from compatible electric, steam, or gas heating configurations, with vessel material, temperature control, insulation, and tilting options determined by the model and your production needs. Contact Wenzhou Ace Machinery to discuss a setup for sauces, soups, jams, dairy mixtures, and more.
100L Industrial Jacketed Cooking Kettle with Agitator
价格范围：$1,802.52 至 $1,939.51
Request a quote
A food grade stainless steel kettle offers many advantages, like easy cleaning, resistance to corrosion, and durability. Its scraper mixing system allows continuous movement of product, prevents sticking and burning, and promotes heat transfer. The handwheel provides adjustable tilting to allow easy disposal of processed product and the motor allows for stable and reliable mixing.
Main Features
- Food-grade stainless steel construction for hygiene and durability
- Jacketed heating system for fast and even heat distribution
- Built-in scraper agitator to prevent sticking and improve mixing efficiency
- Powerful motor drive system for stable operation
- Tilting kettle design for easy material discharge
- Independent control box for convenient operation
- Heavy-duty support frame for enhanced stability
- Suitable for cooking, boiling, mixing, and concentrating various food products
Main Components
- Motor: Provides driving power for the mixing system
- Scraper: Continuously mixes materials and prevents product adhesion
- Kettle Body: Stainless steel processing chamber with jacketed heating structure
- Handwheel: Controls kettle tilting for convenient discharge
- Control Box: Manages machine operation parameters
- Support Frame: Provides stable and safe equipment support
Jacket heating for cooking and processing
Slow-speed mixing and product circulation
Scrapes material from the kettle wall
Helps reduce sticking and localized overheating
Suitable for cooking, simmering, and mixing viscous products
Combines jacket heating, scraping, and high-shear mixing
Helps produce smoother emulsions and more uniform mixtures
Reduces certain types of agglomeration
Suitable for products requiring finer dispersion or emulsification
100L Jacketed Cooking Kettle with Agitator
Heating a viscous sauce evenly while keeping it moving is a practical production challenge: direct heat can expose product to hot surfaces, while manual stirring becomes difficult as batch size grows. This 100L kettle uses an indirect heating jacket to transfer heat through the vessel wall. An agitator is available to support product movement during cooking; its suitability depends on the recipe and selected configuration.
Built around your process
Choose from SUS304 or SUS316L stainless steel, with material selection guided by product chemistry, cleaning practices, and the production environment. Heating options include electric, steam, gas, or thermal oil, subject to model compatibility. Fixed and tilting vessel configurations are available on selected models. Where tilting is offered, operation may be manual or hydraulic. A suitable discharge arrangement should be discussed with us alongside the product’s viscosity and batch handling needs.
Optional temperature control, insulation, a control panel, and variable-speed drive can be considered where compatible. These options can help operators manage heating and agitation during routine batches, but they do not replace recipe trials or process validation. This is a kettle, not an inline rotor-stator mixer; high-shear emulsification and powder deagglomeration should be evaluated separately if the process requires them.
Typical applications
Common food applications include sauces and gravies, jams and fruit fillings, soups, syrups, confectionery mixtures, dairy blends, and fillings. A jam batch may need steady movement to limit sticking, while a dairy mixture may call for careful temperature management. Formulation, viscosity, batch size, and cleaning method all affect the recommended setup. Other industries, including cosmetics, pharmaceutical, and chemical processing, should confirm material, seal, and process compatibility before equipment selection.
Technical specifications
| Product name | Jacketed cooking kettle |
|---|---|
| Available capacity | 50L, 100L, 200L, 300L, 500L, 1000L |
| Material | SUS304 or SUS316L stainless steel |
| Heating | Electric, steam, gas, or thermal oil; model dependent |
| Vessel configuration | Fixed or tilting; model dependent |
| Tilting | Manual or hydraulic where applicable |
| Agitation | Optional agitator; configuration dependent |
| Temperature control | Optional; configuration dependent |
| Customization | Available according to process requirements |
FAQ
Can every capacity use every heat source? No. Availability depends on the selected model and requirements.
Is tilting standard? No. Fixed or tilting construction depends on configuration.
What details help with selection? Share product, batch size, heat source, viscosity, agitation needs, and discharge preference.
Can the kettle handle every food recipe? No. We review product properties and cleaning requirements before recommending a setup.
Can it be used outside food processing? Potentially, after confirming material and seal compatibility and process suitability.
Request a configuration review
Wenzhou Ace Machinery provides factory-direct manufacturing and customization. Send your target capacity, product, preferred heating method, and agitation or tilting requirements. Include batch conditions and discharge needs so our team can review a suitable configuration for your process.
