Configure a sanitary jacketed kettle for jam, sauces, soups, syrups, dairy mixtures, and other batch-processing needs. Available in 50 L to 1000 L capacities, with SUS304 or SUS316L construction and electric, steam, gas, or thermal-oil heating options depending on the model. Agitation, temperature control, insulation, and fixed or tilting designs are available subject to configuration.
Sanitary Jacketed Kettle for Jam, Sauces and Food Processing
Price range: $1,973.00 through $2,111.70
Request a quote
A food grade stainless steel kettle offers many advantages, like easy cleaning, resistance to corrosion, and durability. Its scraper mixing system allows continuous movement of product, prevents sticking and burning, and promotes heat transfer. The handwheel provides adjustable tilting to allow easy disposal of processed product and the motor allows for stable and reliable mixing.
Main Features
- Food-grade stainless steel construction for hygiene and durability
- Jacketed heating system for fast and even heat distribution
- Built-in scraper agitator to prevent sticking and improve mixing efficiency
- Powerful motor drive system for stable operation
- Tilting kettle design for easy material discharge
- Independent control box for convenient operation
- Heavy-duty support frame for enhanced stability
- Suitable for cooking, boiling, mixing, and concentrating various food products
Main Components
- Motor: Provides driving power for the mixing system
- Scraper: Continuously mixes materials and prevents product adhesion
- Kettle Body: Stainless steel processing chamber with jacketed heating structure
- Handwheel: Controls kettle tilting for convenient discharge
- Control Box: Manages machine operation parameters
- Support Frame: Provides stable and safe equipment support
Jacket heating for cooking and processing
Slow-speed mixing and product circulation
Scrapes material from the kettle wall
Helps reduce sticking and localized overheating
Suitable for cooking, simmering, and mixing viscous products
Combines jacket heating, scraping, and high-shear mixing
Helps produce smoother emulsions and more uniform mixtures
Reduces certain types of agglomeration
Suitable for products requiring finer dispersion or emulsification
Jacketed Kettle for Controlled Batch Cooking
Jam production can involve long heating cycles, sticky fruit solids, and frequent scraping or stirring. Choosing a kettle starts with the batch size and the way the product behaves during heating—not capacity alone. At Wenzhou Ace Machinery, we configure jacketed kettles around the product, heat source, and production workflow.
Heat is applied through the space between the inner vessel and outer jacket, warming the product indirectly rather than exposing it to a direct burner. This can help avoid localized heating on the vessel surface. An optional agitator supports product movement during cooking; the suitable design depends on viscosity, solids, and whether the batch needs continuous mixing. It is not a substitute for a high-shear mixer when a process requires intensive emulsification or powder dispersion.
Typical Applications
Food uses include jam and fruit fillings, sauces, gravies, soups, stocks, syrups, confectionery mixtures, and dairy blends. A fruit filling with pieces may need a different agitation approach from a smooth sauce. Salad dressings, mayonnaise, beverage ingredients, and mixtures containing starches, gums, or stabilizers require process review to establish suitable mixing and material choices.
Other industries may use a kettle for creams, lotions, shampoos, liquid detergents, liquid pharmaceutical preparations, or compatible water-based chemical formulations. Confirm product compatibility, cleaning needs, materials, and seals before selecting a configuration; one standard setup is not suitable for every formula.
Specifications
| Item | Details |
|---|---|
| Product name | Jacketed kettle |
| Available capacity | 50 L, 100 L, 200 L, 300 L, 500 L, and 1000 L |
| Material | SUS304 or SUS316L stainless steel |
| Heating | Electric, steam, gas, or thermal oil; model dependent |
| Vessel configuration | Fixed or tilting, depending on model |
| Tilting operation | Manual or hydraulic, where applicable |
| Agitation and temperature control | Optional; configuration dependent |
| Customization | Insulation, variable-speed drive, control panel, and other options subject to compatibility |
Configuration and Ordering
Our factory-direct manufacturing and customization service considers batch volume, product properties, available utilities, heating preference, agitation, and discharge method. Share the target batch size, recipe characteristics, solids content, desired heating arrangement, cleaning process, and installation conditions so our team can review suitable options. Capacities do not automatically support every heating, tilting, or accessory combination.
FAQ
Can every capacity use every heat source? No. Availability depends on the selected model and requirements.
Is an agitator included? It is an optional feature where compatible.
How do I choose SUS304 or SUS316L? Provide ingredients and cleaning chemicals for material review.
Can I request a tilting kettle? Tilting and manual or hydraulic operation depend on the model.
What should I include in an inquiry? Specify capacity, product, heating source, agitation, and tilting needs. Contact Wenzhou Ace Machinery with these details for a configuration discussion.
