Wenzhou Ace Machinery jacketed kettles are available in 50 L to 1000 L capacities, with SUS304 or SUS316L stainless steel and model-dependent electric, steam, gas, or thermal oil heating. Fixed and tilting designs, agitators, temperature control, and other options can be discussed to match your product, batch size, and production process.
Industrial Jacketed Kettle for Food Processing and Cooking
价格范围：$2,115.49 至 $2,234.80
Request a quote
A food grade stainless steel kettle offers many advantages, like easy cleaning, resistance to corrosion, and durability. Its scraper mixing system allows continuous movement of product, prevents sticking and burning, and promotes heat transfer. The handwheel provides adjustable tilting to allow easy disposal of processed product and the motor allows for stable and reliable mixing.
Main Features
- Food-grade stainless steel construction for hygiene and durability
- Jacketed heating system for fast and even heat distribution
- Built-in scraper agitator to prevent sticking and improve mixing efficiency
- Powerful motor drive system for stable operation
- Tilting kettle design for easy material discharge
- Independent control box for convenient operation
- Heavy-duty support frame for enhanced stability
- Suitable for cooking, boiling, mixing, and concentrating various food products
Main Components
- Motor: Provides driving power for the mixing system
- Scraper: Continuously mixes materials and prevents product adhesion
- Kettle Body: Stainless steel processing chamber with jacketed heating structure
- Handwheel: Controls kettle tilting for convenient discharge
- Control Box: Manages machine operation parameters
- Support Frame: Provides stable and safe equipment support
Jacket heating for cooking and processing
Slow-speed mixing and product circulation
Scrapes material from the kettle wall
Helps reduce sticking and localized overheating
Suitable for cooking, simmering, and mixing viscous products
Combines jacket heating, scraping, and high-shear mixing
Helps produce smoother emulsions and more uniform mixtures
Reduces certain types of agglomeration
Suitable for products requiring finer dispersion or emulsification
Jacketed Kettle for Controlled Batch Cooking
Batch size, product thickness, and heat source all affect kettle selection. Our jacketed kettles use an outer jacket to heat the vessel indirectly, helping transfer heat through the kettle wall rather than applying direct heat to the product. This arrangement suits batch cooking where operators need to manage heating and mixing together. Actual results depend on the recipe, batch, and selected configuration.
Wenzhou Ace Machinery manufactures 50 L, 100 L, 200 L, 300 L, 500 L, and 1000 L models in SUS304 or SUS316L stainless steel. Fixed and tilting constructions are available by model. Where a tilting version is compatible, operation may be manual or hydraulic. An agitator, temperature control, variable-speed drive, insulation, control panel, and other custom features can be discussed according to model compatibility. Agitation can support consistent mixing in products such as gravy or fruit filling; the suitable arrangement depends on viscosity and process needs.
Typical Processing Uses
Food applications include sauces, dressings, jams, fruit fillings, soups, broths, gravies, syrups, confectionery mixtures, dairy blends, and fillings. Thick or heat-sensitive recipes may need a different heating and agitation setup than a thin syrup. Related non-food uses—such as creams, lotions, liquid detergents, liquid pharmaceutical preparations, coatings, or water-based formulations—require review of product compatibility, materials, seals, and process requirements before configuration.
Technical Specifications
| Product name | Jacketed kettle |
|---|---|
| Available capacity | 50 L, 100 L, 200 L, 300 L, 500 L, 1000 L |
| Material | SUS304 or SUS316L stainless steel |
| Heating method | Electric, steam, gas, or thermal oil; availability depends on model |
| Vessel configuration | Fixed or tilting, depending on model |
| Tilting option | Manual or hydraulic, where applicable |
| Agitation | Optional agitator; configuration dependent |
| Temperature control | Optional; configuration dependent |
| Customization | Available according to product and process requirements |
Configuration and FAQs
To size a kettle, share the working batch volume, recipe behavior during heating, preferred heat source, mixing needs, and how product will be discharged. Our factory-direct team can review these details and discuss a suitable build; not every capacity supports every heating method or accessory.
- Can every model tilt? No. Fixed or tilting construction depends on the selected model.
- Which steel should I specify? SUS304 and SUS316L are available; confirm product and cleaning compatibility with your team.
- Can an agitator be included? It is an option where compatible. Provide viscosity and mixing objectives.
- Are all heat sources available at every capacity? No. Confirm model and heating compatibility during quotation.
- What should I send for a recommendation? Capacity, product, heat source, agitation, tilting, and discharge requirements.
Send these process details to Wenzhou Ace Machinery for a configuration review and quotation.
